TG-eBank-2 4 1LHYB2

I. Core Advantages

1. Large Capacity + Large Battery Cells

Standard 241 kWh, compatible with 314Ah/320Ah large lithium iron phosphate battery cells (1P16S). No need for mold modification or re-development, directly compatible with mainstream battery cells from major manufacturers. Wide voltage platform: supports 500V–800V high-voltage battery systems, covering domestic and overseas mainstream commercial and industrial storage voltage systems. One set of battery cells can be used for both domestic and export markets.

BMS Deep Customization: Can be customized for balance strategy, protection threshold, and thermal management logic based on the characteristics of the manufacturer's battery cells, improving cycle life and reducing warranty compensation risks.

2. Long Life + High Safety

Ultra-long cycle: Large battery cells + precise BMS balancing + independent liquid cooling temperature control, cycle life ≥ 6000 times (DOD 80%), fully matching the lifespan of large battery cells.

Full-chain safety protection: BMS overcharge / overdischarge / overcurrent / short circuit + high-voltage fuse + perfluorohexanone intelligent fire protection + liquid cooling temperature control linkage, zero safety blind spots from cell level to system level.

High protection + wide temperature range: IP54 cabinet, -20℃–55℃ stable operation, can run stably in outdoor / factory / high-temperature / high-humidity environments.

Same series zero accidents: TG-eBank series has been implemented in batches for many years, no fire, no explosion, no major safety incidents, strong trade promotion reputation, no concerns.

3. High Integration + Easy Deployment

Integrated single cabinet: Battery + PCS + BMS + EMS + liquid cooling + fire protection all integrated, occupying only 1.2㎡, installation and assembly completed in 1 day, deployment cycle shortened by 70%.

Plug-and-play + no debugging: Standard interfaces, factory pre-tuning completed, trade merchants can deliver simply after training, significantly reducing labor and after-sales costs.

Intelligent EMS Cloud Platform: Remote monitoring, automatic fault alarm, remote upgrade, data reports, operation and maintenance costs reduced by 60%+, can manage projects on mobile phones / computers at any time.

4. Efficient and Stable + High Returns

Bidirectional PCS efficiency ≥ 95%, supports 0.5C–1C continuous charging and discharging, compatible with high-frequency scenarios such as industrial and commercial peak-valley arbitrage, backup power supply, and photovoltaic integration.

System energy efficiency RTE ≥ 90%, liquid cooling heat dissipation energy consumption low, lower electricity cost throughout the life cycle, higher IRR for owners (15%–20%).

II. Application Scenarios

1. Large-scale Industrial and Commercial

Large factories / industrial parks: Peak-valley arbitrage (annual return 15%+), backup power supply (production guarantee), photovoltaic integration and consumption, demand charge management.

Large supermarkets / office buildings / complexes: Peak shaving, reducing demand charge, emergency power supply, improving grid stability.

Data centers / communication base stations: UPS-level backup (switching < 20ms), ensuring zero interruption, cost reduction through peak-valley arbitrage.

2. Photovoltaic / Photovoltaic Storage Large Projects

Industrial photovoltaic integration (1MW+): Increase self-consumption rate to 80%+, solve power loss, stabilize fluctuations, battery batch stable delivery.

Photovoltaic storage charging station integration: Storage + photovoltaic + charging, stabilize grid impact, increase charging revenue, 240kWh single cabinet compatible with large charging stations.

Distributed photovoltaic clusters for households / industrial use: Parallel connection of multiple cabinets (maximum 2MW/4MWh), compatible with different scale projects.

3. Grid / Microgrid / Off-grid

Grid area governance / expansion and voltage regulation: overload， improve power supply quality， policy subsidies are abundant， and collection is stable.

Off-grid microgrid (mining / islands / remote areas)： Independent power supply， replacing diesel generators， battery long-term stable supply. New energy power station support: Stabilizing wind and solar fluctuations and enhancing grid connection stability.

4. Advantageous scenarios for traders

Export： 240kWh is the mainstream capacity for large-scale industrial and commercial users in Europe, America, and Southeast Asia. It is convenient for full-container transportation， has favorable tariffs， and offers high single-container profits.

Preferred choice for large projects: Single-container 241kWh， with flexible expansion through parallel connection of multiple containers， suitable for projects of 1MW and above. Traders can handle multiple orders with a single order.

Standardized mass production： Large battery cells + standardized design， with fast batch delivery， stable quality， and simple after-sales service.

III. Solution capabilities

1. For battery manufacturers： Standardized solution for battery cells

Battery cell adaptation service： Provide BMS parameter customization， battery cell balancing debugging， system integration testing， liquid cooling matching. Manufacturers do not need to conduct additional research and development and can directly mass-produce and。

Module integration solution： Support 1P16S standard modules， provide structural design， wiring scheme， and integrated thermal management design， reducing the integration cost for manufacturers and improving production capacity.

Joint warranty： System 5-year warranty， battery 5-year/6000 cycles， joint insurance， risk sharing， and enhancing customer trust.

Flexible production capacity： Can be customized in batches according to manufacturer requirements， flexibly scheduled production， and quick delivery， helping manufacturers absorb large battery cell production capacity and increase added value.

2. For traders： One-stop delivery and operation maintenance solution

Full-process delivery： Scheme design → equipment supply → installation and commissioning → grid connection acceptance → operation and maintenance management. Traders have no need for a professional team and can operate with minimal assets.

Remote operation platform： 7×24-hour real-time monitoring of battery status， charging and discharging data， alarm information， energy efficiency analysis， rapid fault location， and easy after-sales service.

Financial support： Jointly provided by financial institutions with financing lease， installment repayment， EPC advance funding， reducing customer thresholds， and enabling traders to better take orders and receive faster payments.

Market protection： Regional exclusive agency， bottom price supply， price protection， project dividends， with large profit margins and low competition pressure.

3. Customization capabilities

Capacity： 200–241kWh adjustable

Voltage： 500V/600V/700V/800V selectable

Interface： Compatible with mainstream inverters， photovoltaic protocols， and grid standards， seamlessly integrating with existing equipment

Appearance / Protection： Can be customized according to customer requirements for cabinet color， protection level， and interface location

IV. Company strength

1. Technology and R&D strength

Core team with 10 years + experience in the energy storage industry， specializing in industrial and commercial energy storage systems， with independent control of BMS/EMS/PCS/liquid cooling core technologies.

Holds multiple invention patents and software copyrights， continuously iterating， not relying on third parties， and ensuring technical independence.

Deeply adapted to 314Ah/320Ah large battery cells， with leading technologies in long lifespan， high safety， and liquid cooling temperature control.

2. Production and quality strength

Own energy storage system integration factory， with an annual production capacity of 30，000 units +， ISO9001/14001/45001 certification.

Each product undergoes 48-hour full-load aging test +， full-function testing， and passes CE/IEC/UN38.3/UL certifications， ensuring export compliance and stable quality.

Standardized production line + strict quality control， with a short delivery cycle (10–20 days) and strong batch delivery capability.

3. Market and service strength

TG-eBank series has been implemented in hundreds of domestic + overseas projects， covering factories， photovoltaics， microgrids， and exports， with high repeat purchase rates and good reputation.

Domestic 5 major service centers and overseas 8 offices， 365 days ×24 hours technical support， rapid response， and worry-free after-sales service.

Established long-term strategic cooperation with leading battery manufacturers， EPCs， and large traders， with stable supply chain， competitive prices， and complementary resources.

4. Flexible cooperation model

Battery manufacturers: ODM/OEM customization, batch supply of battery cells / modules, joint research and development, joint quality assurance, helping you manage production capacity, increase added value, and expand channels.

Traders: Regional exclusive agent, bottom price supply, market protection, project dividends, financial support, high profit margin, low competition pressure, easy sales and good earnings.
