TG-eBank-215LHYB2

I. Core Advantages

1. 215kWh standard capacity, friendly to large battery cells

Standard 215kWh, compatible with mainstream 280Ah/300Ah/314Ah lithium iron phosphate battery cells (1P16S–1P20S), no need for mold modification or secondary development, directly compatible with large-scale factory production battery cells.

High-voltage platform (650–876V), covering domestic industrial and commercial and European and American export mainstream voltages, one set of battery can be used both domestically and for export.

BMS deep customization: customizable balance strategy, protection threshold, temperature control logic according to the characteristics of the manufacturer's battery cells, improving cycle life and reducing warranty compensation risks.

2. Liquid cooling + long lifespan

Liquid cooling temperature control system (LHYB2 core): temperature control accuracy ±2℃, temperature difference ≤3℃, avoiding hotspots, slow attenuation, cycle life ≥6000 times (DOD80%), and fully matching the lifespan of large battery cells.

Full chain safety protection: BMS + high-voltage protection + perfluorohexane / aerosol fire protection + liquid cooling linkage, full protection from cell level to system level; IP54 outdoor cabinet, stable operation at -20℃ to 55℃.

Zero accident record of the same series: TG-eBank series has been implemented in batches for many years, no fire, no explosion, no major safety incidents, strong promotion reputation of traders, no concerns.

3. Highly integrated + easy deployment

Integrated single cabinet: battery + PCS + BMS + EMS + liquid cooling + fire protection all integrated, small footprint, installation and assembly completed in 1 day, deployment cycle shortened by 70%.

Plug-and-play, no debugging required: factory pre-tuned completed, standard interfaces, traders can deliver simply after simple training, significantly reducing labor and after-sales costs.

Intelligent EMS cloud platform: 7×24-hour remote monitoring, automatic fault alarm, remote upgrade, data reports, operation and maintenance costs reduced by 60%+, can manage projects on mobile / computer at any time.

4. Efficient and stable + high returns

Bidirectional PCS efficiency ≥95%, supports 0.5C–1C continuous charging and discharging, compatible with peak-valley arbitrage, backup power supply, photovoltaic integration, etc. high-frequency scenarios.

System energy efficiency RTE ≥90%, liquid cooling cooling energy consumption low, lower electricity cost throughout the life cycle, owner's IRR 15%–20%.

II. Application Scenarios

1. Main industrial and commercial scenarios

Large factories / parks: peak-valley arbitrage (annual return 15%+), backup power supply, photovoltaic absorption, demand charge management.

Supermarkets / office buildings / complexes: peak shaving, reducing demand charge, emergency power supply.

Data centers / communication base stations: UPS-level backup (switching <20ms), peak-valley cost reduction.

2. Photovoltaic / photovoltaic storage integration

Industrial commercial photovoltaic (500kW–2MW): increase self-consumption rate to 80%+, solve power loss, stabilize fluctuations.

Photovoltaic storage charging integration: storage + photovoltaic + charging, stabilize grid impact, improve charging returns, 215kWh single cabinet compatible with medium-sized charging stations.

3. Grid / microgrid / off-grid

Substation governance / expansion and voltage regulation: alleviate overload, improve power supply quality, subsidies are many, collection is stable.

Mining / islands / remote areas: off-grid microgrid, replacing diesel generators, battery provides long-term stable supply.

4. Trader advantage scenarios

Export： 215kWh is the golden capacity for industrial and commercial storage in Europe and Southeast Asia， convenient for container transportation， tariff-friendly， high profit per cabinet.

Flexible expansion： 215kWh per single cabinet， multiple cabinets connected to 1MW/4MWh， suitable for all projects， large battery cells + standardized design， quick batch delivery， stable quality， simple after-sales.

III. Solution Capability

 1. For Battery Manufacturers: Standardized Solution for Large Battery Cells

Cell Adaptation Services: Customization of BMS parameters, balancing adjustment, system integration testing, liquid cooling matching. The manufacturer does not need to conduct additional research and development and can directly go into mass production.

Module Integration Solution: Supports 1P16S – 1P20S standard modules, providing integrated design for structure, wiring, and thermal management, reducing integration costs and enhancing production capacity.

Joint Warranty: System 5-year warranty, battery 5-year / 6000 cycles, joint insurance, risk sharing.

Flexible Capacity: Batch customization, flexible scheduling, rapid delivery, helping the manufacturer absorb large battery cell capacity and increase added value.

2. For Distributors: One-stop Delivery and Maintenance Solution for Large Projects

Full-process Delivery: Scheme design → Supply → Installation and commissioning → Grid connection → Maintenance management. The distributor has no need for assets and does not need to maintain a professional team.

Remote Maintenance Platform: 7×24-hour real-time monitoring of battery status, charging and discharging data, alarms, energy efficiency analysis, quick fault location, and easy after-sales service.

Financial Support: Leasing, installment, EPC advance funding, reducing customer thresholds, better order acceptance, and faster return on investment.

Market Protection: Regional agents, bottom price supply, price protection, project dividends, large profit margin, low competition pressure.

3. Customization Capability

Capacity: Adjustable from 200 to 215 kWh

Voltage: 650V / 750V / 800V options

Interfaces: Compatible with mainstream inverters, photovoltaic protocols, grid standards, seamless integration with existing equipment

4. Company Strengths

1. Technical R&D Strength

Core team with 10 years + experience in the energy storage industry, focusing on commercial and industrial energy storage, independently controllable core technologies for BMS/EMS/PCS/liquid cooling.

Multiple invention patents and software copyrights, continuous iteration, not dependent on third parties.

Deeply adapted to large battery cells ranging from 280Ah to 314Ah, industry-leading long-life liquid cooling technology.

2. Production and Quality Strength

Own energy storage system integration factory, annual production capacity of tens of thousands of units, ISO9001/14001/45001 certification.

Each unit undergoes 48-hour full-load aging + and full-function testing, passing CE/IEC/UN38.3/UL certifications, export compliance, stable quality.

Standardized production lines + strict quality control, delivery cycle of 10–20 days, strong batch delivery capability.

3. Market and Service Strength

TG-eBank series has been implemented in hundreds of domestic + overseas projects, covering factories, photovoltaics, microgrids, exports, with high repeat purchase rate and good reputation.

Domestic multiple service centers, overseas multiple country offices, 365 days × 24 hours technical support, rapid response.

Long-term strategic cooperation with leading battery manufacturers, photovoltaic EPCs, and large distributors, stable supply chain, competitive prices.

4. Flexible Cooperation Model

Battery Manufacturers: ODM/OEM, batch supply of battery cells / modules, joint research and development, joint warranty, helping you absorb capacity, increase added value, and expand channels.

Distributors: Regional agents, bottom price supply, market protection, project dividends, financial support, high profit, low competition, good sales and earnings.
